This is barn style plan offering 3 Bedrooms, 3-1/2 Bath. The plan offers 2363 square feet with a very open plan.

Footprint: 74'-3" wide by 56'-5" deep, 2,363 heated square feet.

There's no shortage of curb appeal for this beautiful 3 bedroom 3-1/2 bath modern farmhouse plan. The entry and dining room open into a large open living space. The large kitchen has views to the Living Room and Dining Room and features an island with eating bar as well as a large pantry. The 3 bedrooms are well-sized and all include large walk-in closets. With so much to offer, make this your next home today!

An optional Laundry layout is also provided along with an optional Office or Storage on the second floor.

This plan includes all foundation options: Slab foundation, crawl space foundation and basement foundation. The purchase of this plan will provide all information needed for a general contractor for quoting purposes and all information needed for your local building department. Provided are two different files. One 11"x17", a great size for contractors on site and a 24"x36" size, which most building departments require for permits.

Included are the foundation plan, the crawl space plan, the basement plan, the dimensioned floor plans, the framing plan, roof framing plan, the roof plan, door and window schedules, interior and exterior 3D models.

This plan can be customized at an additional fee based on per hour rate. I can also provide a "mirrored" version of the plan.

I also offer custom architectural services to design any other plan you may want.

To make changes to this plan or design your own custom plan, contact Ricky King at or (770)527-7823.

Floor Plan

Included in your purchase:

Click the PDF link to see the completed plan

The Smithfield Barn - Images
